TeleSafe XLN Premium Double Part Scaffoldings
TeleSafe XLN Premium Double Part Scaffoldings
TeleSafe XL Premium model, which is TÜV-SÜD and TSE EN1004 Certified Professional Scaffolding System, can move on its wheels without being mounted on any surface. TeleSafe XL Double Part Scaffoldings have a wider structure than standard TeleSafe model. Extra horizontal braces and toeboards are offered as standard.
in stock
Description
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
| (m.) | (m.) | (m.) | (m.)* | (kg.) | (cm.)** | (WxLxH/cm) | (WxLxH/cm) | ||
| S004_XLN_PR | 2×8 | 2,50 | 3,90 | 2,75 | 4,55 | 95 | 125-215×210 | 75x225x38 | 39x122x46 |
| S005_XLN_PR | 2×10 | 3,05 | 4,95 | 3,83 | 5,63 | 117 | 125-215×210 | 75x280x38 | 39x122x46 |
| S006_XLN_PR | 2×11 | 3,34 | 5,54 | 4,42 | 6,22 | 121 | 125-215×210 | 75x310x38 | 39x122x46 |
| S007_XLN_PR | 2×13 | 3,87 | 6,35 | 5,23 | 7,03 | 126 | 145-235×210 | 75x360x38 | 39x148x46 |
| S008_XLN_PR | 2×15 | 4,41 | 7,17 | 6,05 | 7,85 | 163 | 145-235×215 | 75x415x45 | 39x154x46 |
Max load capacity 186kg.
* Average safe height with User
** Stabilizer feet size (closed-open)
TECHNICAL DETAILS
– Maximum Load Capacity 186 Kg.
– Rung Dimensions: 30×30 mm.
– Beam Dimensions: 75×25 – (100×25 mm. – S008 XL)
– Platform: 15 mm. Plywood Resistant to Outside Conditions.
KONFIGURASYON TABLOSU
| (kg.) | (WxLxH/mm.) | S004_XLN_PR | S005_XLN_PR | S006_XLN_PR | S007_XLN_PR | S008_XLN_PR | |
| S004XLMTK | 13 | 2 | – | – | – | – | |
| S005XLMTK | 16 | – | 2 | – | – | – | |
| S006XLMTK | 17,8 | – | – | 2 | – | – | |
| S007XLMTK | 19,8 | – | – | – | 2 | – | |
| S008XLMTK | 28 | – | – | – | – | 2 | |
| DA040506XL | 27 | 1 | 1 | 1 | – | – | |
| DA07XL | 28,6 | – | – | – | 1 | – | |
| DA08XL | 28,8 | – | – | – | – | 1 | |
| 75251900SOM | 1,2 | 2 | 2 | 2 | 2 | – | |
| 75251950SOM | 1,4 | – | – | – | – | 2 | |
| PLT155x60 | 13,2 | 1 | 1 | 1 | 2 | 2 | |
| PLT170X60 | 13,8 | – | 1 | 1 | – | – | |
| PLT180X60 | 14 | – | – | – | – | 1 | |
| TEK45678XLAL | 5,7 | 1 | 1 | 1 | 1 | 1 | |
| Q161075AL | 1,25 | – | 4 | – | – | – | |
| Q1620100AL | 1,27 | – | – | – | – | 4 | |
| Q164075AL | 1,27 | – | – | 4 | 4 | – | |
| Q165575AL | 1,28 | 4 | – | – | – | – | |
| Q171075AL | 1,37 | 6 | 8 | 8 | 8 | – | |
| Q1710100AL | 1,40 | – | – | – | – | 8 | |
| Q205075AL | 1,58 | 2 | 2 | 2 | 2 | – | |
| Q2050100AL | 1,6 | – | – | – | – | 2 | |
| Q248075AL | 1,83 | 2 | 2 | 2 | 2 | – | |
| Q2500100AL | 1,86 | – | – | – | – | 4 | |
| AKS000000003 | 0,042 | 12 | 12 | 12 | 12 | 12 | |
| (kg) | 95 | 117 | 121 | 126 | 161 |
